Micro Canal

Micro Canal

When floor space is limited, the Micro Canal super-shallow trench heating still provides a powerful heat output. With its advanced height adjustment, from 6-8cm, the depth can be altered to align with all flooring types. The efficient heat exchanger saves energy costs while remaining ultra-responsive to temperature changes.

Low voltage DC-controlled technology improves airflow and provides a powerful output. This gives the Clima Canal full compatibility with low flow temperature systems, such as heat pumps.

  • Only 6 cm high and 13 cm wide
  • Minimalistic aesthetics and architectural freedom with a power that breaks all temperature records
  • By using the latest EC motors, up to 50% less electricity consumption

Grill Types

Stainless Steel Lacquered
Stainless Steel

Find the Perfect Output

wdt_ID Height[cm] Length[cm] Width[cm] Heating 75/65/20 [Watt] Heating 45/35/20 [Watt] Sound Pressure dB(A) Electric power consumption [Watt] Air flow
1 Alle Alle Alle
2 6 60 14 390 153 18,00 1.6 29,30
3 6 95 14 780 306 21,00 1.9 58,50
4 6 130 14 1.170 460 22,80 2.2 88,00
5 6 165 14 1.560 613 24,00 3.1 117,00
6 6 200 14 1.950 766 25,00 3.5 146,50
Height[cm] Length[cm] Width[cm]
